Marathon Motors X030, 1/4HP, 115/230V, 1625RPM, 1PH, TEAO, 48YZ FR
These motors are designed for many of the varied applications found on the farm. Designs include motors suitable for aeration fans, auger drives, grain stirring, metering pumps, instant reversing, irrigation tower drives, and crop driers.
These motors are designed for many of the varied applications found on the farm. Designs include motors suitable for aeration fans, auger drives, grain stirring, metering pumps, instant reversing, irrigation tower drives, and crop driers.
- HORSEPOWER 1/4
- ENCLOSURE TEAO
- FRAME 48YZ
- BRAND Marathon Motors
- MOUNTING Resilient Base/Stud
- MOTOR RPM 60Hz 1625
- RPM 1625
- PHASE 1
- VOLTAGE 115/230
- SERVICE FACTOR 1
- THERMAL PROTECTION Automatic Protector (under locked rotor only)
- AMBIENT TEMP C 40
- ROTATION CCW
- ENCLOSURE TYPE Totally Enclosed
- OPPOSITE END BEARING Ball
- WEIGHT 20 (9.09 kg)
- UL Recognized Construction and Protector
- CSA Y
- DUTY Continuous AOM
- MANUFACTURERS PART NUMBER X030
- RPM RANGE 1501-1700
- INSULATION CLASS B
- FL AMPS 3.6/1.8
- OPPOSITE END BEARING SIZE Ball
- DRIVE END BEARING SIZE 6203
- ASSEMBLY F1 Only
- BEARING-DRIVE-END 6203
- ORIENTATION Horizontal
- IP CODE 43
- STARTING TYPE PSC 1 Speed
- NEMA DESIGN Special
- CATALOG NUMBER X030
- KVA-CODE F
- is_motor Yes
- KILOWATS 0.19
- MODEL NUMBER 48A17T118
