Bimba-Mead Pilot Solenoid Valve M4V110-06-24VDC, 5 Port, 2 Pos, Single, 1/8" NPT, 24VDC, Cv=0.67

Rollover image to zoom in

Click image to enlarge

See all 60 items in product family

Bimba-Mead Pilot Solenoid Valve M4V110-06-24VDC, 5 Port, 2 Pos, Single, 1/8" NPT, 24VDC, Cv=0.67

Item #: WBB571686

Usually ships in 5 to 8 days (ships from US) Estimated lead times do not include weekends or holidays. Transit time is determined by shipping method and destination. Orders requiring credit information might take additional time.

0 reviews | Write a review

Price: $ 68.95
Product Information
Customer Review
Product Q&A
Bimba-Mead Pilot Solenoid Valve M4V110-06-24VDC, 5 Port, 2 Pos, Single, 1/8" NPT, 24VDC, Cv=0.67

M4V110-06 piloted single solenoid valves are 4-way, 1/8 in NPT port, spool style valves. They are stackable and provide a 2-position, normally closed, spring return operation. The M4V110-06 series valves can be used in individual valve applications or multiple valves can be assembled together on a manifold to share supply air which simplifies the piping. They are compatible with the M100M series manifolds. The DIN connector includes an LED indicator. Valves equipped with a turning manual override.

Product Specifications

    • LENGTH INCHES3-29/32 (9.93 cm)
    • WIDTH INCHES5/64 (1.8 cm)
    • HEIGHT INCHES2-11/64 (5.51 cm)
    • BRANDBimba-Mead
    • TYPE5 Port 2 Position
    • LUBRICATIONNot Required
    • POWER CONSUMPTION2.5 W
    • PROTECTIONIP65 (DIN 40050)
    • VOLTAGE RANGE±10%
    • FLOWCv = 0.67
    • PRESSURE22 to 120 PSI
    • ACTUATIONInternally Piloted
    • TEMPERATURE RANGE23∼140°F
    • MANUFACTURER PART NUMBERM4V110-06-24VDC
    • INSULATIONClass F
    • MEDIAAir
    • POWER CONNECTIONDIN / LED Connector
    • PORT SIZE1/8" NPT
