Leeson Motors - 3HP, 230V, 3450RPM, TEFC, Round Mount

Leeson Motors - 3HP, 230V, 3450RPM, TEFC, Round Mount

Item #: WBB217412

Not Yet Rated

Enter postal code for delivery date estimate

Shipping to 10465 change

Price: $1,480.00

Quantity

Customers Also Viewed

Leeson Motors - 3HP, 230V, 3450RPM, TEFC, Rigid Mount, 1.0 S.F.

Leeson Motors - 3HP, 230V, 3450RPM, TEFC, Rigid Mount, 1.0 S.F.

Leeson Motors - 3HP, 230V, 3450RPM, TEFC, Round Mount, 1.0 S.F.

Leeson Motors - 3HP, 230V, 3450RPM, TEFC, Round Mount, 1.0 S.F.

Leeson Motors - 1.5HP, 115/230V, 3450RPM, TEFC, Round Mount, 1.0 S.F.

Leeson Motors - 1.5HP, 115/230V, 3450RPM, TEFC, Round Mount, 1.0 S.F.

Leeson Motors - 2HP, 115/208-230V, 3450RPM, TEFC, Rigid Mount, 1.0 S.F.

Leeson Motors - 2HP, 115/208-230V, 3450RPM, TEFC, Rigid Mount, 1.0 S.F.

Leeson Motors - 1HP, 115/208-230V, 3450RPM, TEFC, Rigid Mount, 1.15 S.F.

Leeson Motors - 1HP, 115/208-230V, 3450RPM, TEFC, Rigid Mount, 1.15 S.F.

Woodworking Motor: 3HP, 3450RPM, 145 Frame, Totally-Enclosed, Fan-Cooled (TEFC), 230V, 1PH, Continuous duty, Manual thermal protection, 1.0 Service Factor, Round Mount.

Motor is designed for woodworking equipment such as table saws, planers, etc. Totally enclosed design prevents motor problems caused by wood dust and shavings.



Weights & Dimensions

  • Shaft Diameter 7/8
  • Weight 56 lbs (25.45 kg)

Product Details

  • Nameplate Amps 13 A
  • Mounting Location C-Face Footless
  • RPM 3450 rpm
  • Rotation CCW °
  • Efficiency Type Standard
  • Material Rolled Steel
  • Ambient Temperature 40 °C
  • Efficiency 81.5
  • RPM Range 3001-3600 rpm
  • Shaft End Bearing 6205
  • Voltage 230 V
  • Frame 145TC
  • Service Factor 1.0
  • Enclosure Type Totally Enclosed
  • Horsepower 3 HP
  • Is_Motor Yes
  • Duty Continuous
  • Design Capacitor Start Capacitor Run
  • Enclosure TEFC
  • Phase 1
  • Compatible Part/Model Number Marathon, C276
  • UPC 69172001612
  • Brand Leeson
  • Motor RPM 60 Hertz 3450 rpm
  • Thermal Protection Manual
  • Hertz 60 Hz
  • Manufacturers Part Number 120824.00

Compliance & Certifications

  • CSA Certified Y
  • UL Y
