Construction:
- Terminal Screws: #8-32 Brass, Silver Finish on Neutral Screw, Green Finish on Grounding Screw
- Face Terminal Assembly: Impact Modified Nylon
- Cord grip: Impact Modified Nylon
- Cover: High-Impact, V-O Valox
- Terminal Cover: Clear Polycarbonate
- Plug Blades: Brass
- Terminal Clamp Nut: Zinc-Plated Steel
- Assembly Screws: Zinc-Plated Steel
- Terminal Identification: Brass-Hot; Green-Grounding; Silver-Neutral
- Terminal Accommodation: #18-#10 AWG Flexible Cord
- Dielectric Voltage: Withstands 1500V per UL498
- Maximum Working Voltage: 250V AC or DC
- Current Interrupting: Certified for current interrupting at full rated current
- Temperature rise: Less than 30 deg C temperature rise at full rated current after 50 cycles overload at 150% rated current for either AC or DC applications per UL498
- Cord Grip Range: 245"-655" (62-166)
- Flammibility: HB or Better per UL94
- Operating Temperature: Maximum Continuous 60 deg C, Minimum -40 deg C (w/o impact)
- NEMA#: 5-15P
- Cord Accomodation: Round portable service cords in accordance with device ratings as defined in UL standard 62, CSA C222 No49
- UL Standards: UL Listed to Standard 498 (Attachment Plugs and Receptacles)
- CSA Standards: Cetrified to CSA Standard C222 No 42M1984 (General Use Receptacles)
- Ul Listing: UL Listed File #E1381- Guide #AXUT
- CSA Certification: CSA Certified File #LR16215- Guide 20T2
- Federal Specifications: Federal Specification WC596 (where applicable)
- Complies With: NEMA Standards WD-1, WD-6
- Overseas_Approval: NOM, CE
Product Specifications
- MADE IN THE U.S.A.Yes
- VOLTAGE125
- BRANDBryant
- AMPERAGE15
- COLORBlack
- POLES AND WIRES2 Pole, 3 Wire
- GRADEHeavy Duty
- TYPEPlug
- MANUFACTURERS PART NUMBER5966VBK
- NEMA5-15P
