Bryant 71430MBWP Weather Protective Power Inlets, L14-30, 30A, 125/250V, Aluminum

Bryant 71430MBWP Weather Protective Power Inlets, L14-30, 30A, 125/250V, Aluminum

Item #: WBB215903

Not Yet Rated

Enter postal code for delivery date estimate

Shipping to 10465 change

Price: $111.95

Quantity

Customers Also Viewed

Construction:
  • Mounting: FS/FD
  • Terminal Cover: Clear Polycarbonate
  • Face Terminal Assembly: Impact Modified Nylon
  • Cover housing: Super Tough Nylon
  • Terminal Clamp Nut: Zinc-Plated Steel
  • Plug Blades: Brass, (neutral blade nickel-plated)
Technical Specs:
  • Dielectric Voltage: Withstands 3500V per UL498
  • Maximum working Voltage: 600V AC or 250V DC
  • Current Interupting: Certified for current interrupting at full rated current
  • Temperature rise: Maximum 30 deg C temperature rise at full rated current after 50 cycles of overload at 150% rated current for either AC or DC applications per UL498
  • Terminal Identification: (X, Y Z Brass Hot) (G, Green, Grounding) (W, Silver, Neutral)
  • Flammability: UL 94 V2 Minimum
  • Configuration Type: L14-30
  • Operating Temperatures: -40 deg C to 85 deg C (continuous w/o impact)
Standards:
  • UL Standards: UL Listed to Standard 498 (Attachment Plug and Receptacles)
  • UL Listing File: Ul Listed File #E2258- Guide #RTRT
  • Federal Specifications: Federal Specifications WC596 (where applicable)
  • Complies With: Complies with NEMA Standards WD-1, WD-6 and UL 498
  • Overseas Approval: NOM, CE
  • CSA Standard: Certified to CSA Standard C222 No42M1984 (General Use Receptacles) and C222 No 1822M1987 (Industrial Locking Type, Special Use Attachment Plugs, Receptacles and Connectors) where applicable
  • CSA Certification File: CSA Certified File #LR16215- Guide #365-E-1

Product Specifications

  • MADE IN THE U.S.A.Yes
  • VOLTAGE125/250
  • BRANDBryant
  • TERMINAL ACCOMODATIONS-MINIMUM#14 Solid/Stranded
  • AMPERAGE30
  • COLORAluminum
  • POLES AND WIRES3 Pole, 4 Wire
  • TERMINAL ACCOMODATIONS-MAXIMUM#8 Solid/Stranded
  • TYPEFlanged Inlet/Weatherproof Cover
  • MANUFACTURERS PART NUMBER71430MBWP
  • NEMAL14-30
