Price: $7,068.00
Customers Also Viewed
The BI-TORQ BY-LE-2-100-3800-A-4-P1-VP series 10" lug style automated butterfly valve features a standard cast iron body, SS disc and EPDM seal. The valve has a pressure rating to 150 PSI (10"-12") and a temperature rating of +275°F. The EPDM seals are compatible with a wide range of industries and media type, especially high temperature applications. This version comes complete with a BI-3800-A-4-P1-VP 115VAC electric actuator with a NEMA 4 powder coated enclosure and a 4-20mA positioner card for modulating service. high-visibility dome and limit switches provide position indication. The actuator is rated from 0°F to +150°F with temperature controls available for extreme environments.
Weights & Dimensions
- Width 15-31/32 IN (40.56 cm)
- Length 10 IN (25.4 cm)
- Valve Size 10 IN (25.4 cm)
- Height 23-1/8 IN (58.74 cm)
Product Details
- Actuator Electric
- Package Quantity 1
- Brand Bi-Torq
- Actuation Type Modulating
- Material Cast Iron, SS, Aluminum
- Manufacturers Part Number BY-LE-2-100-3800-A-4-P1-VP
- Valve Type Butterfly
- Actuated or Manual Actuated
- Respirator Connection Type Lug
Customer Review
Product Q & A
There are no questions for this product.
BI-TORQ 10" Lug Style Butterfly Valve W/ EPDM Seals and NEMA 4 115VAC Electric/4-20mA
